Product Description
PPR stable pipe combines the advantages of PP-R pipe and metal pipe. Enables the composite pipe high rigidity, high temperature resistance, high toughness ,low linear expansion coefficient that recover the limitations of deformation when the plain PPR pipe use for stand pipe, unfold install, and hot water pipeline.
Anti Oxygen Permeability :
Since the high strength aluminum alloy protects the inner PP-R pipe like an armour, Xindew PP-R/AL Steady Pipe can completely prevent the outside air from running into the pipe. Therefore it keeps the water in the pipe free from oxygen and restrains the growth of algae. This feature of the pipe can protect the equipment material from oxidation and prolong the service life of heating equipment and central air-conditioning system. It insures the safe, reliable and high efficient operation of the system.
The pipe can be used for cold/hot water outdoor installation and featuring no deformation, no fading and aging, longer operating life.
Excellent Compressive strength and good anti-temperature
Heat fusion connection and no leakage
Heat preservation and power saving. Coefficient of thermal conductivity is 0.23-0.24 W/M.K.oC, near the insulation material, thus more power is saved.
Pipe Range
Pipes are available in the following diameters:
Outer Dia (mm) |
Wall Thickness (mm) |
Length Mtr |
Weight Kg/Mtr |
20 |
3.4 |
4 |
0.172 |
25 |
4.2 |
4 |
0.266 |
32 |
5.4 |
4 |
0.434 |
40 |
6.10 |
4 |
0.671 |
50 |
8.4 |
4 |
1.050 |
63 |
10.5 |
4 |
1.650 |
75 |
12.5 |
4 |
2.340 |
Advantages / Properties
- Light weight
- Easy transportation
- Easy laying / Installation
- Flexible and at the same time good impact strength
- UV radiation resistant
- Weather resistant
- Excellent chemical resistant(detail available)
- Resistant to growth of bacteria, Algae and fungi
- Long length with fewer joints, available in coils, ideal for hilly areas
- Freeze resistant
- Good weld ability
- No maintenance
- Low co-efficient of friction
- Smooth bore
- Non toxic and non-conductive
- Odorless & Tasteless
Field Of Application
- Portable Water Pipes networks for Cold and Hot water installations i.e in residential Buildings, hospitals, hotels, offices and school buildings etc.
- Pipes networks for rainwater utilization systems
- Pipes networks for swimming pool facilities
- Pipes networks for solar plants
- Pipes networks in agriculture and horticulture
- Heating Pipes for residential houses
- Pipes networks for industry i.e. transport of aggressive fluids (acids, leys, etc)
- Insertion pipe Relining
Comparison of PPRC Pipes with Conventional Pipe Systems
Pipe Property |
G.IRON Pipe |
Copper Pipe |
Upvc Pipe |
Cpvc Pipe |
Pex-AL-Pex Pipe |
PB Pipe |
UNIQUE PPR-C Pipe |
Service life |
5-10 Years |
50 Years |
30 Years |
50 Years |
50 Years |
50 Years |
50 Years |
Resistance to High Temperature |
Good |
Good |
Bad |
Good |
Good |
Good |
Good |
Hygienic Property |
Bad |
Common |
Bad |
Common |
Good |
Good |
Good |
Recyclable and No Pollution |
No |
No |
No |
No |
Yes |
Yes |
Yes |
Pipe Furring |
Yes |
Yes |
No |
No |
No |
No |
No |
Corrosion-Resistant |
Bad |
Bad |
Good |
Good |
Good |
Good |
Good |
Installation |
Hard |
Hard |
Easy |
Easy |
Easy |
Easy |
Easy |
Price |
Low |
High |
Low |
High |
High |
High |
Common |
Reliability |
Common |
Common |
Common |
Common |
Common |
Common |
Good |
